ISO 7241-A Hydraulic Quick Coupling

The ISO 7241-A series hydraulic quick coupling is a globally standardized, double shut-off fluid connector designed for dependable interchangeability across diverse agricultural and industrial oil lines. Constructed from high-tensile carbon steel and protected by a clean white zinc plating, it incorporates spring-loaded poppet valves in both the socket and the plug halves. This structural layout provides automatic and instantaneous shut-off when disconnected, successfully sealing the media and eliminating system pressure loss. Its classic ball-locking sleeve mechanism enables robust push-to-connect field operations under demanding medium-to-high pressure workflows.

Technical Specifications

• Standard Conformance: Compliant with ISO 7241-A international specifications

• Valving Arrangement: Double Shut-Off Automatic Poppet Valve System

• Structural Material: High-Strength Tough Carbon Steel

• Plating Treatment: White Zinc Plating (Trivalent Cr3+ Zinc Coating)

• Locking Device: Hardened steel locking balls for secure sleeve retention

• Connection Interface: Quick disconnect pull-back sleeve operation

• Thread Port Formats: High-precision Female NPT / BSPP / BSPT threads

• Body Size Availability: Available from 1/4 inch up to 2 inch (3/4" size as depicted)

• Primary O-Ring Seal: High-grade Nitrile (NBR) rubber elastomer

• Extrusion Protection: Heavy-duty PTFE backup ring to handle shifting stress

• Fluid Accommodation: Recommended for mineral-based hydraulic oils and liquids

• Leakage Integrity: Tight poppet closure guarantees zero-drop performance on decoupling

• Internal Geometry: Streamlined valve paths optimize flow rate and lower backpressure

• Wrench Drive Profile: Integrated robust hex flats for straightforward wrench tightening

• Fatigue Performance: Rated to comfortably withstand standard industrial pressure impulses

• Thermal Capabilities: Continuous operational efficiency from -20 to +100 degrees Celsius

• Sleeve Grip Surface: Patterned knurling ensures firm handling during greasy field service

• Dust Cap Integration: Readily compatible with protective PVC or rubber dust plugs

• Interchange Equivalency: Fully interchangeable with all standard ISO A series quick couplers

• Assembly Alignment: Precision machining keeps plug and socket aligned during high-stress vibration

• Quality Verification: 100% factory hydrostatic proof and dimensional adherence inspected
