Cast Steel Valves

  • Carbon steel Fully welded ball valve reduced bore Full Bore
  • Carbon steel Fully welded ball valve reduced bore Full Bore
  • Carbon steel Fully welded ball valve reduced bore Full Bore
Carbon steel Fully welded ball valve reduced bore Full BoreCarbon steel Fully welded ball valve reduced bore Full BoreCarbon steel Fully welded ball valve reduced bore Full Bore

Carbon steel Fully welded ball valve reduced bore Full Bore

  • Fully Welded
  • Reduced bore or Full Bore
  • welded ball valve
  • uni ball valve
  • Description: Carbon steel Fully welded ball valve reduced bore
  • INQUIRY   EMAIL

Full Bore or Reduced bore;


Material:
Body: ST37.0/A106/Steel 20
Ball: SS304
Stem: 2Cr13
Stem seal: FPM or VITON
Ball seal: RPTFE (PTFE+C)


Pressure Rating:PN10-PN40;Class150-Class300;
DN 10-250/200: With handle
DN 250-500: Without handle; by request with
gear operator, pneumatic or electric drive


OPERATION
Connection dimensions acc. to GOST on default / (EN) DIN on request
DN 10-250: lever – painted carbon steel with polymer end
DN 125-250: manual gearbox with worm gear recommended
DN 250-600: manual gearbox on default
Gearbox in horizontal arrangement on default
