Stainless steel jacketed gate valve for bitumen

This heavy-duty full jacketed wedge gate valve is manufactured from premium CF8 (SS304) stainless steel, explicitly designed to handle viscous fluids that solidify at ambient temperatures. By welding an outer steel jacket onto the valve body and equipping it with independent flanged heating ports, the valve allows smooth circulation of hot thermal oil or steam to maintain a consistent processing temperature. Its flexible wedge design ensures tight sealing and low operational torque, making it a dependable choice for asphalt plants, oil refineries, and chemical processing facilities.

Technical Specifications

• Valve Design Classification: Bolted Bonnet OS&Y (Outside Screw and Yoke) Jacketed Gate Valve

• Body Material Standard: Stainless Steel CF8 / ASTM A351 / EN 1.4308

• Jacket Enclosure Structure: Fully Welded External Heating Jacket Shell

• Main Line Pressure Rating: PN16 / Nominal Pressure 1.6 MPa

• Heating Jacket Pressure Rating: PN10 / 1.0 MPa Max Permissible Pressure

• Main Process Connections: RF (Raised Face) Flanged Ends

• Jacket Media Connections: Flanged Inlet and Outlet Ports for Uniform Heating

• Internal Wedge Configuration: Flexible Wedge with Precision Ground Sealing Faces

• Seat Trim Combination: Coaxial Stainless Steel 304 Integral Sealing Surfaces

• Stem Mechanical Profile: Rising Stem with Precision ACME Power Threads

• Stem Seal Assembly: Die-Formed High-Purity Flexible Graphite Packing Rings

• Body-to-Bonnet Gasket: Spiral Wound Stainless Steel with Flexible Graphite Filler

• Flow Optimization: Full Bore Design to Prevent Media Accumulation and Clogging

• Operation Interface: Heavy-Duty Cast Iron Manual Handwheel (Blue Coated)

• Manufacturing Design Base: API 600 / ASME B16.34 / ISO 10434 Compliant

• Main Flange Geometry Standard: EN 1092-1 / DIN 2501 (Oversized to clear jacket shell)

• Casting Integrity Method: Advanced Investment Precision Casting Procedure

• Surface Cleaning Protocol: Uniform Mechanical Shot Blasting and Acid Passivation

• Target Industrial Media: Bitumen, Liquid Asphalt, Molten Sulfur, Heavy Crude, High-Viscosity Resins

• System Quality Certification: Produced under Certified ISO 9001 Operations
